Engineering Consultation
With nearly 40 years of experience, we can meet with your project team on-site at your facility (engineering, quality control, safety, production, and operators) to clearly define the application and the expected productive output of the project.
Installation Services
Positech can supply supervised installation (turnkey or partnership) with local contracted installation personnel or your internal maintenance personnel to assure a safe, efficient installation.
Integration Services
Positech can source and supply entire work cell solutions that may include lift assists, lift tables, conveyors, overhead rails, carts, fixtures, and other ergonomic solutions for a total project solution.
Operator and Maintenance Personnel Training
After a new piece of equipment or process is installed in your facility, it is very important that the operators, production people and maintenance personnel are trained to operate and maintain this installation safely and efficiently.
Planning & Layout Design
Positech can supply 2D and/or 3D layouts and profiles of the existing area and the product flow and production enhancement of the completed project.
Long-Term Service Support
Positech has 24-hour phone support, preventative maintenance services and spare parts support for the life of the equipment.
Case Studies
- Industry: Mining
- Challenge: Cylindrical
Limited work space, multiple obstacles, and heavy parts lead to ergonomic problems. Restricted power sources and underground environmental conditions limited the available equipment to perform the tasks. The end-user was looking for a solution to improve operator ergonomics as well as the overall efficiency of this maintenance process.
- Industry: Agriculture, Construction, Military and Defense
- Challenge: Engine Handling
Heavy parts were being mounted to an engine on a hanging conveyor and engines are allowed to sway. Operators had to crawl under the engine to insert shields onto installed housing with only 6″ clearance.
- Industry: Agriculture, Automotive, Construction, Military and Defense
- Challenge: Glass Handling
Safe3ly pitch heavy glass panels varying in size, weighing up to 150 lbs. up to 110°, from vertical to horizontal and rotate through the pitched horizontal axis to line up holes for installation.
- Industry: Metal Production
- Challenge: Engine Handling
Long parts are laying horizontal on the welding table at a 30° down angle. The catalytic converter is towards the operator. Parts are placed into the rack vertically and the catalytic converter is away from the operator at at a 15° forward angle. Intake tube on the bottom of the part is lifted over and onto a 3″ stud. exhaust tube snaps into clips at the top of the rack.
- Industry: Paper
The rolls are very heavy and expensive to manufacture. The largest roll is 63″ in length, 30″ in diameter and weighs 1,450 lbs. While core diameter remains constant at 6″, the length, width, and weigh vary. Vertical travel is a concern in order to be able to retract the material handling device in the vertical orientation. Operator safety is top priority when considering the weight of the rolls to be handled.
Lifting and inserting the counterweight, which may weigh up to 65 lbs., creates several ergonomic issues. There is a 10′ dropped ceiling above the counterweight staging area. The opening in the cabinet is only 1″ larger than the counterweight, which requires the pitched up counterweight be perfectly aligned for insertion. The cabinet is traversing the work cell moving by on a powered conveyor.
- Industry: Agriculture, Construction, Military and Defense
- Challenge: Engine Handling
The system capacity rating must be able to accommodate larger oil pans that may be manufactured at a future date. The radial reach and capacity requirements create significant moment loads. Work Cell contains obstructions and low headroom.
- Industry: Automotive
- Challenge: Engine Handling
Existing hydraulic manipulator was not as effective at placing bars on the paint line hanger as a pneumatic manipulator would be. The “float” capability of a pneumatic manipulator and ease of maintenance convinced the customer to replace their hydraulic manipulator.
